HGrant Warm Mix System

Warm mix asphalt is an excellent way to lower your asphalt temperature, reduce fuel consumption and waste, save money, and it helps your asphalt manufacturing as well as the environment.

Our HGrant Warm Mix System is the best way to utilize warm mix asphalt. This simple to operate system runs efficiently and features a selector switch on the operator’s panel that allows for manual selection of the number of gallons per minute for output. When in manual or “hand mode,” the rate of output can be adjusted using the Manual Speed Pot dial. When set at 10, the highest level, there will be three gallons per minute of output.

The water levels in the water tank are monitored by a 3 level switch. The high-level switch shuts the water off on the refill process. The medium level switch signals when water needs to be refilled and begins that process. The low-level switch shuts the pump off and indicates that there is a low level of water through a warning light at the operator’s panel.

In addition to these features, the HGrant Warm Mix System is easy to install and maintain. Its water injection creates foaming micro-bubbles and it is compatible with any make asphalt drum plants. It has a 54-gallon automatic refill aluminum water tank and the system is rated up to 600 TPH. The low water alarm system and injection pump ensure that the system always has the correct amount of water. Finally, the control system blends well with existing controls.

If you have a hot mix asphalt plant or are a hot mix paving company, the HGrant Warm Mix System is potentially a very beneficial addition. The system allows you to save on asphalt cost per ton through reduced fuel costs and limited waste. To learn more about the HGrant Warm Mix System or to obtain a free estimate, call us today. Our team is ready and able to help you find the right solutions.
